Introduction

This article is primarily about the Lumix S1 and its Lumix lenses, but it's from the point of view of a Leica shooter. It’s actually the first time I’ve written about anything other than a Leica release, but I have owned many of the recent cameras from Fuji, Nikon and Sony (Canon have just slipped me by, accidentally rather than by intent).

Panasonic UK have been kind enough to lend me the S1, the 24-105, 70-200 and 50 f1.4 lenses. Thank you Mike!

Lumix S1 with Lumix S 50/f1.4 1./640 at f1.4

I have been using L mount cameras for nearly 6 years now (I received my first test copy of the Leica T in October 2013). That was an innovative and exciting camera, and many people are still devoted advocates. Since then there has been the TL, the TL2 and the CL in the APSc range, and the SL which arrived in June 2015 (on my desk at least, it was announced in October).

Leica had understood that making better lenses for mirrorless cameras needed a larger lens mount; this is something that both Canon and Nikon have realised with their recent releases, whereas Sony simply used their APS/c mount for their full frame cameras.

Lumix S1 with Leica APO Vario Elmar 90-280 f2.8/f4 1/800th f3.8

I don’t think the photographic press really knew what to make of the SL, it was before the Sony full frame cameras were taken so seriously, at any rate, it didn’t get the reception it deserved. It is still a fine camera, and has been my workhorse for events and weddings for the last 4 years (with brief excursions with the Sony A7ii and the Nikon D850).

I was very excited when the L mount alliance between Leica, Panasonic and Sigma was announced at Photokina in 2018. It promised exciting new bodies and a whole range of excellent (and more affordable) lenses, filling in the gaps and offering more specialist lenses as well.

The Lumix S1 and S1R are the first tangible offspring of this alliance, and the S1 is what I’ve been looking at for the last couple of months. I chose the S1 rather than the S1R because I wanted to look at it in context with the SL (which is also 24 mp).

Texting - Lumix S1 with Lumix 24-105 f4 . 1/400 f4

The Camera and Lenses

I’m not going to go into huge detail about the camera and its functions, there are innumerable reviews around the internet which go into the last detail, so this will be an overview of my feelings about the design of the camera and lenses.

The Lumix S1 is a substantial camera, weighing in at 899 gm as opposed to 847 gm for the Leica SL. The body shape of the two cameras is quite similar, but the S1 has much rounded corners and a shaped and contoured grip. I’ve never found the Bauhaus like design of the SL to be a problem (except possibly when banging it against my hip!), but the Lumix is certainly conventionally well designed and comfortable to hold for long periods of time.

My own feeling is that if you are going to use a full frame camera, then you will inevitably end up toting substantial lenses, in which case it’s easier with a more substantial body that you can really get hold of. There is about 250 gm difference in weight between a Sony A7 and the Lumix S1, I really don’t see that could possibly be a deal breaker for anyone

Texting - Lumix S1 with Lumix 70-200 f4 . 1/250 f4

I think it’s really interesting to see how the design philosophy of different manufacturers varies so much with respect to controls on mirrorless cameras. Leica remain minimalist in their control layout, whereas Sony have gone down the route of adding many function buttons with options for infinite configuration. Fuji have embraced the idea of having literal and slightly retro controls and dials for everything. Canon and Nikon have pretty much stuck to their well established dSLR options.

With the S1 Panasonic have supplied a button for almost every photographic option, these are labelled properly, and the design layout and feel of the controls means that it’s very easy to change them with your eye to the viewfinder (and with gloves on if necessary). The only surprise omission is that there isn’t a dedicated button for the metering mode, I’ve used one of the front function buttons for this.

Texting - Lumix S1 with Lumix 24-105 f4 . 1/1600 f10

If you don’t like the standard layout, then you can re-purpose any of the buttons to do pretty much anything you like. The menu system is logically laid out, and easy to navigate (there are a lot of options though!). I found that after a week, and having made up some user presets I really didn’t need to delve into the menus much.

Living in the UK, proper weather sealing is of real importance to me, if I go out for a days shooting I like to be able to keep on if there is a downpour (and I certainly don’t like having to put my camera into a bag). I’ve taken the S1 out in really horrible weather and it has behaved immaculately; no steaming in the viewfinder and absolutely no water ingress in any of the compartments.

Pednvounder - Lumix S1 with Lumix 24-105 f4 . 1/400 f10

The ‘Kit Lens’ the 24-105 f4 is a really good workhorse of a lens, no frills, but no vices either. I used it almost exclusively for the Ladies Tractor Road Run pictures, it focused fast and without issue, and it’s quite usable at all focal lengths and all apertures. It’s relatively light, very good ergonomically and very sharp. It might not be quite as stellar as the Leica 24-90, but it’s considerably lighter and about a third of the price!

Bracken - Lumix S1 with Lumix 70-200 f4 . 1/250 f4

The 70-200 f4 is a different animal, it’s a cracker of a lens, very very sharp from 70-200 and from f4 to f11, with good out of focus areas (bokeh). It also has a focus ‘clutch’ mechanism which I first saw on Olympus micro four thirds lenses. When you pull slightly on the focusing ring there is manual focus option with a proper distance scale. I found this very useful and it’s well implemented.

Thank You - Lumix S1 with Lumix 50mm f1.4 . 1/250 f4

The Lumix 50mm f1.4 is a beast of a lens. Zeiss began the trend of producing very high quality ‘standard’ lenses with the Otus, this lens is a worthy inheritor of the same philosophy. Once you have got over quite how big it is (weighing in at just under 1kg) both the operation and the results make it all seem well worth while. Like the 70-200 it has a ‘clutch’ manual focus option, in addition it has a silky smooth aperture dial with an ‘A’ to allow Aperture priority automatic. The auto-focus is fast and silent, it has excellent bokeh and is incredibly sharp with a real presence.

Hover- Lumix S1 with Leica R 60mm macro Elmar 1/250

L mount lens interchangeability

If the L mount standard is really going to take off, then there must be proper compatibility between all the different lenses and bodies. I have been in a good position; I already have 2 L mount bodies (the SL and the CL), together with 5 Leica lenses (24-90 SL, 90-280 SL, 75 APO SL, 18-56 TL (APS-c) and the 55-135 (APS-c)). I also had the 3 current Lumix lenses (as above).

If you put the Lumix lenses on to the CL you get a warning about a reduced battery life; I thought that using the 70-200 it was about half the usual number of shots, the 24-105 perhaps 3/4. Presumably this is to do with the optical image stabilisation (although you don’t get the same message with the SL zooms, both of which also have image stabilisation.

Leaving- Lumix S1 with Leica 75mm APO Summicron SL 1/640 f2

I tried all the combination of lenses I could think of and they all worked perfectly well. I guess the APS-c lenses would be more attractive on the S1-R, when the cropped image is just over 20mp (it’s around 10 on the S1).

These are very promising results, it suggests that everyone is sticking rigidly to the L mount standard. I can imagine many photographers mixing lenses from all three members of the consortium. It’s going to be exciting when the Sigma Art lenses are released later on this year.

Wild Rose- Lumix S1 with Leica 75mm APO Summicron SL 1/1000 f2

M Mount Lenses on 3rd Party bodies

There are three different issues which commonly occur when using M mount lenses on non-Leica bodies, and it’s better to understand these when considering using traditional Leica lenses on 3rd party bodies

Excess Vignetting
Colour shift across the frame
Smearing of detail away from the centre of the frame

Leica lenses (and other M mount lenses) are more likely to suffer from these problems in that the angle of incidence of light to the sensor is more oblique than it is with the ‘tele-centric’ lenses which most modern cameras use. The problem becomes more pronounced when the rear element of the lens is closest to the sensor (which is towards infinity).

Lots of people with various different cameras have pronounced them to work well with M lenses having done tests at 2 or 3 metres distance on test charts or similar, but it’s at longer distances that problems become obvious (think landscape in particular).

Studious- Lumix S1 with Leica 50mm APO Summicron M 1/1000 f2

Excess Vignetting and Colour shift (1 and 2 above) are fixed by a combination of a special design of micro lenses on the sensor, together with firmware correction. Also an additional light sensor on the SL and M cameras which is used to assess the aperture (which then goes in the exif information). This estimated f stop value is then used to get the right correction for vignetting.

3rd party companies (such as CornerFix) have produced software to fix these problems after the event, and much can be done in processing software such as Lightroom. This works well, and the only downside is likely to be a little increase in noise in the corners (and a big increase in processing time).

Of course, to make this work properly the firmware/software needs to know which M lens has been used, so that the correct profiles can be applied.

Drinking Dolly - Lumix S1 with Leica 50mm APO Summicron M 1/320 f2

Smearing of detail with M lenses is caused by having a thicker cover-glass over the sensor: Kolari have well understood this and provide modifications for many cameras. They replace the cover glass with a much thinner one and this greatly reduces smearing with M mount lenses (although of course it doesn’t fix issues with colour shift or vignetting). Smearing cannot be fixed after the event by software, once the detail has gone, then it really has gone.

Lenses designed for dSLR cameras (and modern mirrorless cameras) have a light path which strikes the sensor much nearer to the vertical, even at infinity. For camera manufacturers who don’t have issues with the angle of incidence of light then a thicker cover glass is actually beneficial, firstly because it makes IR filtration much easier and secondly because dust on the sensor is much less visible if it’s further from the sensor (because it’s more out of focus).

Thinking Theodolite - Lumix S1 with Lumix 24-105 f4 1/60 f4

Most camera manufacturers put a stack of glass on top of the sensor:

clear glass to protect the sensor from dust, humidity etc (usually glued)
A glass IR Cut filter - usually mechanically fixed
An Anti-aliasing filter to stop moire (less used with modern high res cameras).

This stack can be up to 3mm in thickness

The M10 only has an IR cut filter, which is 0.8mm whilst the SL has clear glass filter plus an IR cut filter which is 1.2mm in total (which explains why the SL is not quite as good with difficult M lenses as the M10).

It is also worth pointing out that the cover glass thickness can vary with different versions of the same sensor, and that although the cover glass thickness is part of the L-Mount specification it does allow a range of thickness in order not to limit alliance members in using different cover glass technology or use of optical low pass filters (for example for professional video).

St Just Tapas - Lumix S1 with Leica 50mm APO Summicron M 1/5000 f2

These issues were real problems for Leica when producing the first digital rangefinder cameras and remains an issue to be solved with each new camera. They have worked really hard to make sure that all their cameras which will accept M mount lenses will work properly with them (SL, CL, TL etc.).

Of course, this is not a priority for other camera manufacturers, who obviously want you to buy their lenses rather than Leica ones!

As a result of this, it’s no surprise that the Panasonic S1 doesn’t play so well as the Leica SL or CL (and especially the Leica M) with the more problematic M lenses (for instance the 28 Summicron Asph and the 35 Summicron Asph). It may not be a problem for street photography where you’re usually more interested in the centre of the frame, and where you’re not usually shooting near infinity. But smearing will certainly rear its ugly head if you plan to do landscape or anything else where resolution is really important off-axis.

The S1 does read the 6 bit code (although it only collects the focal length of the lens) so that as long as you use the Leica adapter the correct focal length goes into the exif information (the same is true with R lenses although, rather bizarrely it reads my 60mm macro elmarit R as 61mm! ), but it cannot apply any vignetting or colour cast compensation, because it doesn’t have the extra light sensor to estimate the aperture, or the actual lens characteristics.

It's worth mentioning here that some others I have spoken to have not managed to pick up the focal length with the S1, but it has worked perfectly for me.

Thank You - Lumix S1 with Lumix 24-105 f4 1/80 f4

The Pink Lady Problem (a case study)

For the last 8 years, on the first Sunday of July, it’s been my job to photograph the Pink Ladies Tractor Road Run. This event is run in aid of Breast Cancer Research and in the 16 years it’s been running it has raised over £640,000.

Around 120 tractors (mostly vintage) are driven 25 miles around the Norfolk and Suffolk lanes and offroad on tracks through the fields. The tractors are decked in pink, and so are the women who drive them.

At 4 different points around the course I try to get at least one picture of every lady. The tractors are travelling at around 10 mph, sometimes very close together. The weather has varied from pouring rain to baking sunshine. Perfect for the drivers is puffy white clouds and a decent breeze (meaning that the light changes completely every time the sun goes in or comes out).

Pink Emma - Lumix S1 with Lumix 70-200 f4 1/160 f5

So the problem is two fold. Getting good focus, and getting a good exposure.

First of all getting good focus - the speed of the tractors and the light means that it’s not really possible to zone focus and keep a relatively small aperture.

Auto focus presents its own problems, because the tractors are very different sizes (and therefore the height of the lady varies) it’s not possible to set a focus point to use on the face which suits all tractors. Face detection has tended to focus on the front of the tractor (two headlight eyes I suppose), as does any kind of area AF.

Done It! - Lumix S1 with Lumix 24-105 f4 1/500 f5.6

Then there is the exposure problem. This is multi faceted; some ladies wear hats, some are under umbrellas or canopies, some are behind glass windows of cabs and others are bare headed and open to the elements (sun or rain). The English weather dictates that most years it will be bright sunshine one minute and thick cloud cover the next (and pouring with rain ten minutes later!). This year I didn’t need to test the weather sealing of the S1, anyway I’ve already done that very thoroughly and it seems to be excellent.

When shooting a wedding or event it isn’t usually necessary that all the images should be usable, but in the case of the Pink Ladies this is vital (I don’t wish to confront an angry Norfolk farmer whose picture I failed to get!). This isn’t just a technical problem when shooting, but it’s also a post processing problem - if you have 800 images which you want to post quickly online, then it’s not much good if you have to spend more than a few seconds on each image getting it right! That means it’s important to get the white balance, exposure and framing correct out of the camera.

No Photos Please - Lumix S1 with Lumix 24-105 f4 1/800 f5.6

For the previous 3 years I’ve shot The Ladies Tractor Road Run with the Leica SL, this worked pretty well, although the AF was often a challenge, not so much because of the speed, but getting the lady in focus rather than the front of her tractor. Images with the driver heading towards the camera were usually okay, but shots from side on (generally within about 10 feet with the tractor going at 10mph) were always quite tricky (and sometimes unusable).

I had been shooting with the Lumix S1 for about 6 weeks, and having chickened out and shot a couple of weddings with the SL I resolved to put the S1 through it’s paces for the Pink Ladies.

Hallooo - Lumix S1 with Lumix 24-105 f4 1/200 f6.3

After some trial attempts I set up the camera as follows

Lens

I used the Lumix 24-105 F4, it would have been nicer to use a fixed focal length, but with the varying sizes of the tractors this really wasn’t realistic

White Balance

Daylight White balance (sunshine symbol). This is to reduce the need to fiddle about with the colour temperature in post processing.

Exposure

I used centre weighted exposure mode (exposure mode seems the only control in the camera which doesn’t have its own button - I set it to use Fn1 on the front. I set M on the PASM dial with the shutter speed to 1/500th (enough to catch the action at 105mm) and the Aperture to f6.3. I then set the Auto ISO to a maximum of 6400 ISO (in fact it didn’t get much above 1600). So I was using a sensible compromise with shutter speed and aperture and the auto ISO to get the exposure right.

Auto Focus

I used Face Detect AF in the hope that the new AI controlled algorithm in the S1 could tell the difference between a real face (in a pink hat) and the front of a tractor with two eyes and a radiator nose!

I put the camera on continuous AF, and both focus and exposure control on the shutter release.

Annie Arriving - Lumix S1 with Lumix 24-105 f4 1/800 f5.6

The Results

The camera really performed - picking out faces on tractors unerringly and getting a really high hit rate - even side on shots where the drivers were very close and travelling fast worked well (often even getting eye focus). The exposure settings meant that there was very little exposure tweaking needed in post processing, and the WB setting meant that it looked sunny when it was, and cloudy when it was cloudy!

I’ve read criticisms of the depth by defocus AF of the Lumix cameras, but for this task it really worked.

What’s more it was a pleasure to shoot - I didn’t really need to think about the camera at all, which left me free to attract the driver’s attention and get the shots I needed (even through the open side windows of cabs at 10mph!).

Gurnards Head - Lumix S1 with Lumix 24-105 f4 1/125 f4

Conclusion

The Panasonic S1 is a cracking camera, right up for wedding, event, landscape and casual shooting, and I’d happily use it for sport as well, the only rider being that I didn’t completely investigate the tracking options (I like to use continuous AF and single shot mode).

The body and control layout is excellent and the camera is lovely to shoot with, even for a long day event. The buttons and dials fall easily to hand and I like the fact that they are labelled well (and the lit labels are really cool when shooting in low light).

The two ‘Leica certified’ lenses, the 70-200 f4 and the 50 f1.4 are really excellent quality (although I found the 50 a bit heavy for my purposes). The 24-105 f4 is also really good - no vices and excellent image quality, especially considering the price. The two f4 zooms are relatively light and both of them handle well on both the S1 and the SL

Logan's Rock - Lumix S1 with Lumix 24-105 f4 1/1250 f4

This has been an encouraging experience, I realised that the Lumix interface would be quite different from Leica, but different isn’t necessarily bad, (I loved using the Lumix G9 last year). I found it really quite easy to swap between the S1 and my SL. Both of them pass my test of good camera ergonomics (you can put them down for a fortnight and then pick them up and use them without having to think).

What I was hoping to find was that a mixed set of bodies and lenses would provide a consistent experience, and, basically that’s what I have found. My only caution is that Leica M lenses are not part of the L mount standard, and my findings suggested that they didn’t work as well on the Lumix bodies (no criticism, why should they?)

Mackerel Sky, scallops and chilli - Lumix S1 with Lumix 24-105 f4 1/60 f4

All the combination of L lenses worked really well with each other (full frame and APS/c). I can easily imagine adding an S1R to an SL kit to provide higher resolution for Landscape and product work. Equally I can imagine adding an S1 as a second (or first) body for events, or adding a couple of Leica lenses to a Lumix kit (especially the wonderful SL summicron lenses). Personally I’m seriously considering adding the Lumix zooms to my SL kit (and perhaps a body later on). I haven’t mentioned the Sigma Art lenses, and their fine long telephotos, because I haven’t tried them, but on the evidence seen here (and my previous experiences with Sigma) I’m sure they’ll also perform really well.

Panasonic UK have been really communicative and helpful and I would certainly be most happy to put myself at the mercy of the Panasonic Professional Imaging Department, and that isn’t a small consideration when thinking of buying into a new system.

It’s fantastic to see 3 companies working together to create a new standard, and my experience running 2 of the systems together suggests to me that it has a great future.
